Tracking Electricity Data with InfluxDB

"""Ingest data from Electricity Maps Data Portal CSV."""
from pathlib import Path

import pandas as pd
from influxdb_client import InfluxDBClient


def _transform_datestr(datestr: str):
    x_dt = datetime.fromisoformat(datestr)  # Date is in UTC
    return x_dt.isoformat(timespec="microseconds")


path_to_csv = Path("path/to/downloaded.csv")
emaps_df = pd.read_csv(path_to_csv)
relevant_data = emaps_df[
    ["Zone Id", "Carbon Intensity gCO₂eq/kWh (LCA)", "Datetime (UTC)"]
]
df_mapped = relevant_data.rename(
    columns={
        "Zone Id": "zone",
        "Carbon Intensity gCO₂eq/kWh (LCA)": "gci",
        "Datetime (UTC)": "time",
    }
)
influx_opt = {
    "bucket": "bucket name, e.g. squirrel",
    "measurement": "measurement name, e.g. electricity_maps",
    "field": "field name, e.g. carbonIntensity",
    "tags": {"zone": "zone of data, e.g. DE", "emissionFactorType": "lifecycle"},
}
zone_ids = df_mapped["zone"].unique()
assert len(zone_ids) == 1
influx_opt.get("tags").update({"zone": zone_ids[0]})
df_mapped.loc[:, "time"] = df_mapped["time"].apply(_transform_datestr)
client = InfluxDBClient(...) # Setup client with token etc.
with client.write_api() as writer:
    for _, row in data.iterrows():
        record = {
            "measurement": options["measurement"],
            "fields": {options["field"]: row[value_column]},
            "tags": options["tags"],
            "time": row[time_column],
        }
        writer.write(bucket=options["bucket"], record=record)

version: '3'

services:
  influxdb:
    image: influxdb:2
    container_name: influxdb
    hostname: influxdb
    volumes:
      - type: volume
        source: influxdb2-data
        target: /var/lib/influxdb2
      - type: volume
        source: influxdb2-config
        target: /etc/influxdb2
    ports:
      - "8086:8086"
    networks:
      - naturegrid
  telegraf:
    image: telegraf:latest
    container_name: telegraf
    depends_on:
      - influxdb
    volumes:
      # Mount for telegraf config
      - ./telegraf.conf:/etc/telegraf/telegraf.conf:ro
    environment:
      - INFLUX_URL=http://influxdb:8086
      - INFLUX_TOKEN=influx-api-token
      - INFLUX_ORG=your-org
      - INFLUX_BUCKET=your-bucket
      - EMAPS_TOKEN=electricity-maps-api-token
      - EMAPS_URL=https://api.electricitymap.org/v3/carbon-intensity/history?zone=DE
    networks:
      - naturegrid

volumes:
  influxdb2-data:
  influxdb2-config:

networks:
  naturegrid:
    driver: bridge

# Configuration for telegraf agent
[agent]
  ## Default data collection interval for all inputs
  interval = "10s"
  ## Rounds collection interval to 'interval'
  ## ie, if interval="10s" then always collect on :00, :10, :20, etc.
  round_interval = true

  ## Telegraf will send metrics to outputs in batches of at most
  ## metric_batch_size metrics.
  ## This controls the size of writes that Telegraf sends to output plugins.
  metric_batch_size = 100

  ## Maximum number of unwritten metrics per output.  Increasing this value
  ## allows for longer periods of output downtime without dropping metrics at the
  ## cost of higher maximum memory usage.
  metric_buffer_limit = 100

  ## Collection jitter is used to jitter the collection by a random amount.
  ## Each plugin will sleep for a random time within jitter before collecting.
  ## This can be used to avoid many plugins querying things like sysfs at the
  ## same time, which can have a measurable effect on the system.
  collection_jitter = "2s"

  ## Default flushing interval for all outputs. Maximum flush_interval will be
  ## flush_interval + flush_jitter
  flush_interval = "30s"
  ## Jitter the flush interval by a random amount. This is primarily to avoid
  ## large write spikes for users running a large number of telegraf instances.
  ## ie, a jitter of 5s and interval 10s means flushes will happen every 10-15s
  flush_jitter = "1s"

  ## By default or when set to "0s", precision will be set to the same
  ## timestamp order as the collection interval, with the maximum being 1s.
  ##   ie, when interval = "10s", precision will be "1s"
  ##       when interval = "250ms", precision will be "1ms"
  ## Precision will NOT be used for service inputs. It is up to each individual
  ## service input to set the timestamp at the appropriate precision.
  ## Valid time units are "ns", "us" (or "µs"), "ms", "s".
  precision = "1s"

  ## Log at debug level.
  # debug = false
  ## Log only error level messages.
  quiet = false

  ## Name of the file to be logged to when using the "file" logtarget.  If set to
  ## the empty string then logs are written to stderr.
  logfile = ""

  ## The logfile will be rotated after the time interval specified.  When set
  ## to 0 no time based rotation is performed.  Logs are rotated only when
  ## written to, if there is no log activity rotation may be delayed.
  # logfile_rotation_interval = "0d"

  ## The logfile will be rotated when it becomes larger than the specified
  ## size.  When set to 0 no size based rotation is performed.
  # logfile_rotation_max_size = "0MB"

  ## Maximum number of rotated archives to keep, any older logs are deleted.
  ## If set to -1, no archives are removed.
  # logfile_rotation_max_archives = 5

  ## Pick a timezone to use when logging or type 'local' for local time.
  ## Example: America/Chicago
  # log_with_timezone = ""

  ## Override default hostname, if empty use os.Hostname()
  hostname = "telegraf"
  ## If set to true, do no set the "host" tag in the telegraf agent.
  omit_hostname = false

[[outputs.influxdb_v2]]
  ## The URLs of the InfluxDB cluster nodes.
  ##
  ## Multiple URLs can be specified for a single cluster, only ONE of the
  ## urls will be written to each interval.
  ##   ex: urls = ["https://us-west-2-1.aws.cloud2.influxdata.com"]
  urls = ["${INFLUX_URL}"]

  ## Token for authentication.
  token = "${INFLUX_TOKEN}"

  ## Organization is the name of the organization you wish to write to; must exist.
  organization = "${INFLUX_ORG}"

  ## Destination bucket to write into.
  bucket = "${INFLUX_BUCKET}"

  ## The value of this tag will be used to determine the bucket.  If this
  ## tag is not set the 'bucket' option is used as the default.
  # bucket_tag = ""

  ## If true, the bucket tag will not be added to the metric.
  # exclude_bucket_tag = false

  ## Timeout for HTTP messages.
  # timeout = "5s"

  ## Additional HTTP headers
  # http_headers = {"X-Special-Header" = "Special-Value"}

  ## HTTP Proxy override, if unset values the standard proxy environment
  ## variables are consulted to determine which proxy, if any, should be used.
  # http_proxy = "http://corporate.proxy:3128"

  ## HTTP User-Agent
  # user_agent = "telegraf"

  ## Content-Encoding for write request body, can be set to "gzip" to
  ## compress body or "identity" to apply no encoding.
  # content_encoding = "gzip"

  ## Enable or disable uint support for writing uints influxdb 2.0.
  # influx_uint_support = false

  ## Optional TLS Config for use on HTTP connections.
  # tls_ca = "/etc/telegraf/ca.pem"
  # tls_cert = "/etc/telegraf/cert.pem"
  # tls_key = "/etc/telegraf/key.pem"
  ## Use TLS but skip chain & host verification
  # insecure_skip_verify = false

# Read formatted metrics from one or more HTTP endpoints
[[inputs.http]]
  ## One or more URLs from which to read formatted metrics
  urls = ["${EMAPS_URL}"]
  headers = {"auth-token" = "${EMAPS_TOKEN}"}
  data_format = "json"
  name_override = "electricity_maps"
  tagexclude = ["url", "host"]
  json_query = "history"
  json_name_key = "carbonIntensity"
  tag_keys = ["zone", "emissionFactorType"]
  json_time_key = "datetime"
  json_time_format = "2006-01-02T15:04:05Z07:00"
